● Up to 2 x 30 watts PoE Power Budget
● 2 10/100/1000M Ethernet Input port
● 2 10/100/1000M PoE Output port
● IEEE 802.3at / IEEE 802.3af standard compliant
● Plug&play, simple setup with no configuration needed
● Compatible with PoE 802.3af and PoE+ 802.3at Devices
ModelPOE220No. of channels2Pass Through Data Ratesi10/100/1000MbpsPower over Ethernet OutputPin Assignment and Polarity: 1/2 (-), 3/6 (+)Output Power Voltage: 54VDCUser Port Power: 30W maxInput Power RequirementsAC Input Voltage: 100 to 240 VACAC Input Current: 0.8A 100-240 VACAC Frequency: 50 to 60 HzDimensions131mm x 70mm x 40mmIndicatorsSystem Indicator: AC PowerUser Indicator: Channel PowerConnectorsShielded RJ-45, EIA 568A and 568BProtectionOver current protectionOver load protectionOver voltage protectionAnti-interference protectionEnvironmental ConditionsOperating Ambient Temperature: 0 to 40℃Operating Humidity: Maximum 80%, Non-condensingStorage Temperature:-20 to 70℃Storage Humidity: Maximum 80%, Non-condensing
